Pneumatic Crawler Drill KC-115
The KC-115 is a light, compact, and highly reliable drill rig that excels in all its applications. Its robust design ensures excellent performance even in constrained workspaces, offering economical and efficient drilling with easy-to-use manual controls.
features
Light and compact size ensures ease of handling and mobility
Robust and economical component design ensures easy maintenance
Proven components life
Simple and Compact, Easy to Transport
The KC-115 is simple in operation, fully mechanized and self-propelled. This heavy duty drill rig is ideal for work in confined areas due to its compact size. The machine is light enough to be transported easily by various ways.
Single Person Operation, Powerful Traction
The KC-115 is a one-man operated machine. Its tramming controls are located beside the left track and it can tram at 3.2 km/h (2 mph), thanks to the two independent
4.5 hp air motors. The 7.5 hp (5.5 kW) air powered hydraulic pump ensures quick positioning. Even though KC-115 is small in size; it does not lose any of the needed power.
Easy Handling, Capable Drilling
The tracks of KC-115 adapts to any ground irregularities through the oscillating main frame. It is equipped with the rotary head for 3” & 4” down the hole hammers for holes upto 4 ½” (115mm). It is easy to maintain from any angle.
Drill Coverage Area
Specifications
| Carrier | ||
| Tramming Speed, Max | 3.2 km/h | 2,0 mph |
| Track oscillation | ± 20o | |
| KC-115 | ||
| Feed extension | 750 mm | 29.4” |
| Feed rate, max | 0.3 m/s | 59.0 ft/min |
| Feed force, max | 21 KN | 4720 lbf |
| Tractive pull, max | 15 KN | 3372 lbf |
| Total length | 5130 mm | 202” |
| Travel length | 3565 mm | 104.4” |
| Drill Tube Size | Pipe Size | |
| Drill rig | 64, 76 mm | 2.5”, 3” |
| Transport Dimensions | ||
| Height | 2325 mm | 7’7 ½” |
| Length | 5120 mm | 16’9 ½” |
| Width | 1940 mm | 6’4 ½” |
| Weight | 2690 kg | 5930 lb |
